1. This light source supports single channel constant current source output,
2. 1 LED white light source, with a maximum power of 120W.
3. This system supports three 12V DC fan outputs.
4. This system has temperature detection function, supporting 2 temperature detection channels, 1 channel for LED light board temperature detection and 1 channel for constant current source driver board temperature detection. When the LED light board heat sink fan fails, the light guide beam heat sink fan fails, the LED light board is abnormal, or the LED light board temperature detection circuit fails, the LED light board temperature detection will activate the protection mechanism. At this time, the LED white light current output will be reduced, reducing the brightness of the LED white light source. If the temperature detection finds that the temperature has returned to normal, the output current will return to normal. When the temperature detection circuit of the constant current source drive board detects that the temperature of the constant current source drive board is too high, it will reduce the LED white light current output and decrease the brightness of the LED white light source. If the temperature detection finds that the temperature has returned to normal, the output current will return to normal.

This product is a new generation of LED light source independently developed by our company, which can provide LED white light output.
The constant current source driver board supports system upgrades and can be upgraded by sending upgrade files from external hosts. Can support external command control to adjust the brightness of the light source. This light source supports 0-100 level LED white light brightness control, where 100 level is the highest power and the LED white light brightness is the highest, and 0 level is the lowest power and the LED white light source is turned off.
